لیبل پرینتر چاپ بارکد ZMIN X1

  • امکان اتصال از طریق USB,RS-232
  • دارای حافظه 2 MB Flash ROM, 8 MB SDRAM
  • حداکثرعرض لیبل برای چاپ 110 میلی متر

توضیحات

لیبل پرینتر X1 یکی از محصولات شرکت ZMIN می باشد که برای چاپ متون و بارکد های تک بعدی و دو بعدی بر روی کاغذ های پشت چسب دار یا لیبل ، طراحی و روانه بازار شده است. از این جهت از این پرینتر تحت عنوان بارکد پرینتر یا پرینتر بارکد زن نیز یاد می شود.

لیبل پرینتر Zmin X1 از طراحی ظاهری مدرن و کاربر پسندی بهره می برد و در ابعاد ۲۰۸*۳۱۰*۱۹۵ میلی متر و وزن ۲٫۶۲ کیلوگرم ارائه شده است. از پرینتر لیبل زن X1 می توان به عنوان یک لیبل پرینتر رومیزی در فروشگاه ها ، انبارها و محیط های تجاری نیازمند چاپ بارکد بر روی لیبل استفاده کرد.



قابلیت و مشخصات فنی لیبل زن X1

لیبل پرینتر زد مین X1 از لحاظ نوع مواد مصرفی بسیار انعطاف پذیر است. این پرینتر از روش های حرارتی مستقیم و غیر مستقیم برای چاپ بهره می برد و شما می توانید از انواع لیبل های حرارتی ، کاغذی ، متال ، شبرنگ و … یا ریبون های Wax ، Wax/Resin و Resin در آن برای چاپ استفاده کنید.

نکته ای که باید به آن توجه داشت این است که عرض لیبل هایی که قصد استفاده از آن ها را در لیبل زن زد مین X1 دارید حداقل ۲۰ میلی متر و حداکثر ۱۱۴ میلی متر می تواند باشد. همچنین قطر رول لیبل آن ۱۲۷ میلی متر و قطر ریبون مورد استفاده در این پرینتر حداکثر ۷۰ میلی متر است.

چاپگر لیبل زد مین X1 از ریبون هایی با عرض حداکثر ۱۱۰ میلی متر و طول حداکثر ۳۰۰ متر پشتیبانی می کند. همین طور که مشاهده می کنید شما می توانید از لیبل ها و ریبون های دلخواه و در اندازه های متنوع در لیبل پرینتر Zmin X1 بهره ببرید.

سایر مشخصات فنی پرینتر لیبل زن Zmin X1  شامل سرعت چاپ و رزولوشن آن می شود که به ترتیب برابر با ۲۰۳٫۲ میلی متر بر ثانیه و ۲۰۳ dpi است که باعث شده تا فرآیند چاپ با این لیبل پرینتر با سرعت و دقت مطلوبی انجام گیرد.

نکته دیگری که باید به آن اشاره کرد این است که لیبل زن زد مین مدل Zmin X1 قابلیت چاپ در عرض ۱۰۴ میلی متر و طول ۴۰۰۰ میلی متر را دارد و برای پرینت لیبل های بزرگ کاملا مناسب می باشد. لیبل پرینتر Zmin X1 به ۱۶ مگابایت حافظه SDRAM و ۸ مگابایت حافظه فلش مجهز بوده و به شما امکان ذخیره بارکد های مورد نظر برای چاپ و همچنین ذخیره اطلاعات موارد درحال پرینت را می دهد.

برای اتصال کامپیوتر ، لپ تاپ یا دستگاه های دیگر به چاپگر لیبل ZMIN X1 می توان از پورت های USB و سریال تعبیه شده بر روی بدنه این پرینتر بهره برد.

مشخصات :

  • نام لیبل پرینتر : لیبل پرینتر ZMIN X1
  • برند لیبل پرینتر : ZMIN
  • مدل لیبل پرینتر : X1
  • نوع لیبل پرینتر : رومیزی
  • نوع برش : دستی
  • جنس بدنه : پلاستیک
  • پردازنده : bit-32
  • روش چاپ حرارتی مستقیم و غیر مستقیم
  • وزن دستگاه : ۲٫۶۲ KGS
  • ابعاد دستگاه : W208*D310*H195 mm
  • امکان اتصال از طریق USB,RS-232
  • دارای حافظه ۲ MB Flash ROM, 8 MB SDRAM
  • حداکثرعرض لیبل برای چاپ : ۱۱۰ میلی متر
  • حداکثر سرعت چاپ : ۸ IPS
  • دقت چاپ X1=203DPI
  • قابلیت چاپ با انواع ریبون ( وکس ، رزین و وکس رزین )
  • قابلیت چاپ روی انواع لیبل های کاغذی ، پی وی سی ، متال ، تایوک و …



ویژگی ها :

  • قابلیت اتصال به کامپیوتر
  • دارای تکنولوژی چاپ برچسب به چندین زبان
  • سنسور های قابل تنظیم
  • پیش نمایش چاپ
  • چاپ عمودی
  • چاپ افقی
  • چاپ چرخشی



لوازم جانبی :

  • آداپتور برق
  • کابل USB
  • دفترچه راهنما
  • کابل برق



 *دارای یک سال گارانتی مانی پردازش می باشد.

*برای اطلاع از قیمت لیبل پرینتر چاپ بارکد ZMIN X1 با کارشناس فروش تماس حاصل فرمایید.



ZMIN barcode printing label printer

Introducing the Zmin X1 label printer

Label Printer X1 is one of the products of Z Main Company, which is designed and marketed for printing one-dimensional and two-dimensional texts and barcodes on sticky paper or labels. For this reason, this printer is also known as a barcode printer or barcode printer.

Zmin X1 label printer has a modern and user-friendly design and is presented in the dimensions of 208 * 310 * 195 mm and weighs 2.62 kg. The Zinedine X1 Label Printer can be used as a desktop label printer in stores, warehouses and commercial environments that require barcode printing on the label.

Capability and technical specifications of Zed Min X1 label
The Zemin X1 label printer is very flexible in terms of the type of consumables. This printer uses direct and indirect thermal methods for printing and you can use a variety of thermal labels, paper, metal, shebrang, etc. or Wax, Wax / Resin and Resin ribbons for printing.

The point to note is that the width of the labels that you intend to use in the Zed X1 label can be at least 20 mm and at most 114 mm. Also, the diameter of the label roll is 127 mm and the diameter of the ribbon used in this printer is a maximum of 70 mm.

The Zemin X1 label printer supports ribbons with a maximum width of 110 mm and a maximum length of 300 meters. As you can see, you can use your favorite labels and ribbons in a variety of sizes on the Zmin X1 label printer.

Other technical specifications of the Zmin X1 label printer include print speed and resolution, which is equal to 203.2 mm / s and 203 dpi, respectively, which makes the printing process with this label printer to be done with good speed and accuracy.

Another point to note is that the Zmin X1 label is capable of printing 104 mm wide and 4000 mm long, and is perfectly suited for printing large labels.

The Zmin X1 label printer is equipped with 16 MB of SDRAM memory and 8 MB of flash memory, allowing you to save the barcodes you want to print as well as information about the items you are printing.

USB and serial ports built into the body of this printer can be used to connect a computer, laptop or other device to the Zmin X1 label printer.

Specifications

  • Label Printer Name: ZMIN X1 Label Printer
  • Label printer brand: ZMIN
  • _Labelprinter model: X1
  • Type of label printer: desktop
  • Cutting type: manual
  • Body type: plastic
  • Processor: bit-32
  • Direct and indirect thermal printing method
  • Device weight: 2.62 KGS
  • Dimensions of the device: W208 * D310 * H195 mm
  • Ability to connect via USB, RS-232
  • Has 2 MB Flash ROM, 8 MB SDRAM
  • Maximum width of the label for printing: 110 mm
  • Maximum print speed: 8 IPS
  • _Print accuracy X1 = 203DPI
  • Ability to print with different types of ribbons (wax, resin and wax resin)
  •  Ability to print on a variety of paper labels, PVC, metal, Tyuk and etc

Attributes

  • Ability to connect to a computer
  • Has the technology of printing labels in several languages
  • Adjustable sensors
  • Print preview
  • Vertical printing
  • Horizontal print
  • Rotation printing

accessories

  • Power adapter
  • USB cable
  • Manuals
  • Power Cable

Model

X1

X1i

Printing method Direct thermal & Thermal transfer
Resolution

۲۰۳ DPI (8dots/mm)

۳۰۰ DPI(11.8dots/mm)

Maximum print speed

۸ IPS(203.2mm/s)

۶ IPS(152.4mm/s)

Maximum print width

۴٫۰۹″(۱۰۴mm)

۴٫۱۵″ (۱۰۵٫۶mm)

Maximum print length

۱۵۷٫۵″(۴۰۰۰mm)

۷۸٫۷″(۲۰۰۰mm)

Memory ۸ MB Flash ROM, ۱۶ MB SDRAM
Media Roll-feed, die-cut, continuous, fan-fold, tags, tickets in plain paper or thermal
paper
Width:۴٫۵″(۱۱۴mm) max.,0.8″(۲۰mm)min.
Supply roll: OD 5″(۱۲۷mm) max., ID 1″(۲۵٫۴mm) min.
Thickness: 0.08~۰٫۲۰mm(0.003″~۰٫۰۰۷۸″), including liner
Ribbon Wax, Wax/Resin, Resin
Ribbon roll: OD 2.75″(۷۰mm) max. with ID 1″(۲۵٫۴mm) core or ID 0.5″(۱۲٫۷mm) core
Max width: 110mm; Max length: 300M
Media sensor Adjustable reflective & Transmissive
Bar Code Types ۱D Barcode : Code 39,Code 93,Code 128,Codabar,EAN-8/13/128,Interleave
۲ of 5,UCC-128,UPC A/E 2 and 5 add-on, etc.
۲D Barcode : Data Matrix, MaxiCode, PDF417,QR, etc.
Interfaces RS-232 serial, USB
Power rating ۲۴ VDC, 2.5 A
Weight ۲٫۶۲KGS
Dimensions

W208 x D310 x H195 mm

Operation
environment
Temperature: 32° F ~ +104° F (0° C ~ 40° C)
Relative humidity: 5% – 85% non condensing
Storage environment Temperature: -40° F ~ +140° F (-40° C ~ 60° C)
Relative humidity: 5% – 85% non condensing
Optional items

Peeler kit, Internal 100/10 M Ethernet Interface card

 Has a one-year processing warranty

 For information on the price of ZMIN X1 barcode label printer, please contact the sales expert
