توضیحات
بارکد خوان Mindeo2250
بارکد خوان یا اسکنر بارکد دستگاهی است که اطلاعات ذخیره شده در بارکدها را میخواند و در سیستم نرم افزاری ثبت و ذخیره میکند. معمولا، بارکد خوان ها از سه قسمت تشکیل میشوند :
- سیستم نور افشانی
- حسگر
- رمز گشا
به طور کلی دستگاه بارکد خوان با تاباندن نور قرمز به عناصر سیاه و سفید موجود در بارکد آن را اسکن کرده و اطلاعات داخل آن را به متن تبدیل میکند. حسگر یا دیود حساس به نوری که در دستگاه بارکد خوان وجود دارد بازتاب هایی که از تابش نور قرمز به بارکد ایجاد میشود شناسایی میکند و یک سیگنال آنالوگ به بخش رمز گشای دستگاه ارسال میکند. بخش رمزگشا سیگنال را تفسیر کرده و با کمک رقم چک ، صحت و سقم بارکد را تایید نموده و اطلاعات استخراج شده را به متن تبدیل میکند.
ویژگی ها و قابلیت ها :
- قابلیت خواندن بارکد کارت ملی با سرعت بسیار بالا و در زاویه های مختلف
- دستگاه بارکد خوان لیزری و صنعتی
- کاربری آسان و راحت : User friendly بدون نصب Driver در محیط Windows و لینوکس و Os/2 Warp 4
- روشن و خاموش شدن اتوماتیک بارکدخوان بر اساس وجود یا عدم وجود بارکد در زیر دستگاه ( حساس با بارکد )
- رنگ دستگاه : مشکی با قابلیت تمیز شدن آسان
- قابلیت خواندن بارکد دفاتر بیمه تامین اجتماعی
- طول کابل دستگاه : ۲ متر
- دارای پایه مقاوم جهت کاربری آسانتر با قابلیت انعطاف جهت تنظیم دستگاه
- رابط اتصال به سیستم USB/Keyboard/RS 232 ( هر دستگاه قابلیت کار با هر ۳ پورت را دارد. )
- امکان خواندن بارکد ها هم به شکل اتوماتیک و هم بصورت دستی Manual Tigger & Auto Tigger
- سرعت اسکن ۲۰۰ خط در ثانیه قابلیت خواندن بارکد با سرعت بالا در زاویه های مختلف
- قابلیت خواندن بارکد های مخدوش ، بارکد های لمینیت شده یا باروکش سیلفون ( کارت ملی ، گواهینامه ، گذرنامه و … )
- نصب شده در ایران خودرو ، سایپا و صدها سازمان و بانک
- بدنه ضد ضربه نسبت به سطح سخت IP54
- ویژه کارخانجات و فروشگاه های زنجیره ای و سازمان ها با حجم کاری بسیار بالا
- قابل استفاده در فروشگاه ها (طرح کدینگ کالا ) ، اتوماسیون اداری ، انبارداری ، ثبت آسان سریال کالاهای دارای بارکد
*دارای یک سال گارانتی مانی کارت می باشد.
*برای اطلاع از قیمت بارکد خوان Mindeo2250 با کارشناس فروش تماس حاصل فرمایید.
Barcode reader Mindeo2250
A barcode reader (or barcode scanner) is an optical scanner that can read printed barcodes, decode the data contained in the barcode and send the data to a computer. Like a flatbed scanner, it consists of a light source, a lens and a light sensor translating for optical impulses into electrical signals.
- Laser and industrial barcode scanner 2250
- Ability to read the national card barcode at a very high speed and at different angles
- Laser and industrial barcode reader
- Ability to read the national card barcode at a very high speed and at different angles
- Ability to read distorted and faint barcodes
- Easy and convenient: User friendly without installing Driver in Windows, Linux and Os / 2 Warp 4
- Automatic on and off load of code reader based on the presence or absence of barcode under the device (barcode sensitive)
- Device color: Black with easy cleaning
- Ability to read the barcode of social security insurance offices
- Laser class: EN60825-1, Class 1 and 650nm laser diode
- Ability to read barcodes with a minimum width
- (۵mil) for Long-Range series
- (۳mil) for High-Density series
- Device cable length: 2 meters
- Has a sturdy and heavy base for easier use with the ability to adjust the device (black)
- USB / Keyboard / RS 232 connection interface (each device can work with all 3 ports)
- Ability to read barcodes both automatically and manually Manual Tigger & Auto Tigger
- Scanning speed of 200 lines per second Ability to read barcodes at high speeds at different angles
- Ability to read distorted barcodes, laminated barcodes or cellophane barcodes (national card, certificate, passport, etc.)
- Ability to read all barcode standards
- UPC-A, UPC-E, EAN-13, EAN-8, ISBN / ISSN, Code 39, Code 39, full ASCII, Code
- ۳۲, Trioptic Code 39, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5,
- Codabar (NW7), Code 128, Code 93, Code 11 (USD-8), MSI / Plessey, UK / Plessey,
- UCC / EAN 128, China Post, China Finance, GS1 DataBar (formerly RSS) variants
- Installed in Iran Khodro, Saipa, and hundreds of organizations and banks
- Impact body compared to IP54 hard surface
- Especially for factories, chain stores and organizations with a very high workload
- Can be used in stores (product coding plan), office automation, warehousing, easy registration of serial goods with barcodes
- Barcode scanning angle: ± ۶۰ °, ± ۶۵ °, ± ۴۲ °
Has a one-year processing warranty
For information on the price of Mindeo2250 barcode reader, please contact the sales
